Apollo x16 Heritage Edition Review
Live prices and creator coverage for the Apollo x16 Heritage Edition - everything in one place.
Our editorial take on the Apollo x16 Heritage Edition
The Universal Audio Apollo x16 Heritage Edition is a rackmount audio interface designed for professional studio environments. Its 18x20 I/O configuration, combined with Thunderbolt 3 connectivity, positions it for high-channel count recording and mixing applications. A key feature is its Real-Time UAD Processing, which enables users to run powered plug-ins with minimal latency, differentiating it from interfaces that offload all processing to the host computer.
This interface emphasizes digital purity and high fidelity, as indicated by its 24-bit AD/DA conversion and impressive dynamic range and THD+N figures across its line and monitor outputs. The inclusion of a special UAD plug-in bundle adds value for users already invested in or looking to integrate Universal Audio's ecosystem. Its rackmount form factor and professional-grade sync options (Word Clock, AES3) further cement its place in a dedicated studio setup.
Consideration should be given to its specific I/O, which focuses on line and monitor connections via DB-25 and XLR, omitting built-in microphone inputs, phantom power, or instrument inputs. This suggests it is intended to be integrated into a larger system with external preamplifiers and DI boxes. The absence of MIDI I/O or expansion slots also narrows its application profile to core audio conversion and processing.
- Real-Time UAD Processing for near-zero latency plug-in use
- High-resolution 24-bit conversion with up to 192 kHz sample rate
- Excellent dynamic range and low THD+N specifications for line and monitor outputs
- Comprehensive digital sync options including Word Clock and AES3
- Includes a special UAD plug-in bundle
- Lacks built-in microphone preamps, phantom power, or instrument inputs
- No MIDI I/O or expansion slots
- Requires external preamplifiers for microphone recording
- Specific I/O via DB-25 connectors may require additional cabling or breakout boxes
Synthesized by Geared editors from early expert reviews.
Community ratings
Real ratings from people who own the gear.
No written reviews yet. Be the first to share your thoughts.
About this product
The Universal Audio Apollo x16 Heritage Edition is a rackmount 18x20 Thunderbolt 3 audio interface designed for professional audio production. It features Real-Time UAD Processing, allowing users to run UAD powered plug-ins with near-zero latency. This edition includes a special bundle of UAD plug-ins.
Specs
- Pad
- No
- Weight
- 9.0 lb / 4.1 kg
- Display
- 18x Multi-Segment LED Meter
- Latency
- 1.1 ms at 96 kHz (Input to Output)
- MIDI I/O
- No
- Sync I/O
- 1x BNC Word Clock Input 1x BNC Word Clock Output
- Wireless
- -
- Solo/Mute
- Mute per Master
- Bit Depths
- 24-Bit (AD/DA Conversion)
- Dimensions
- 19 x 13.5 x 1.8" / 48.3 x 34.3 x 4.6 cm (Including Controls and Protrusions)
- Form Factor
- Rackmount
- Network I/O
- No
- Built-In DSP
- -
- Sample Rates
- -
- Sync Sources
- AES3, Internal, Word Clock
- Phantom Power
- No
- AC Input Power
- 100 to 240 VAC, 50 / 60 Hz
- Rackmount Size
- 1 U
- USB (Non-Host)
- No
- Expansion Slots
- No
- Analog Audio I/O
- 2x DB-25 Line/8-Channel Input 2x XLR 3-Pin Monitor Output 2x DB-25 Line/8-Channel Output
- High-Pass Filter
- No
- OS Compatibility
- macOS 10.12 to 10.15 / Windows 10 or Later
- Digital Audio I/O
- 1x XLR 3-Pin AES3 Input 1x XLR 3-Pin AES3 Output
- Power Consumption
- 30 W (Typical) 72 W (Maximum)
- Required Hardware
- Available Thunderbolt 3 Port
- Power Requirements
- AC/DC Power Adapter (Included)
- AC/DC Power Adapter
- 12 VDC at 6 A (Included)
- Built-In Microphone
- -
- THD+N (Line Inputs)
- -115 dB / 0.00018% (1 kHz, +23 dBu Input)
- Storage Requirements
- 6 GB
- THD+N (Line Outputs)
- -123 dB / 0.000068% (1 kHz, at -1 dBFS)
- Maximum Sampling Rate
- 192 kHz / 24-Bit
- Processor Requirement
- Intel Core i7
- Impedance (Word Clock)
- 75 Ohms
- Media/Memory Card Slot
- No
- Sample Rate Conversion
- No
- Impedance (Line Inputs)
- 10 Kilohms
- THD+N (Monitor Outputs)
- -129 dB / 0.000037% (1 kHz, at -1 dBFS)
- Host Connection Protocol
- Thunderbolt 3
- Dynamic Range (Line Inputs)
- 124 dBA
- Mobile Device Compatibility
- No
- Number Of Microphone Inputs
- No
- Dynamic Range (Line Outputs)
- 127 dBA
- Dynamic Range (Monitor Outputs)
- 133 dBA
- Clocking (Word Clock Lock Range)
- 44.1 to 192 kHz ±4% of Sample Rate
- Frequency Response (Line Inputs)
- 20 Hz to 20 kHz ±0.05 dB
- Impedance (Line/Monitor Outputs)
- 100 Ohms
- Frequency Response (Line Outputs)
- 20 Hz to 20 kHz ±0.02 dB
- Maximum Input Level (Line Inputs)
- +24 dBu (Balanced, +4 dBu) +6.2 dBV (Balanced, -10 dBV)
- Frequency Response (Monitor Outputs)
- 20 Hz to 20 kHz ±0.2 dB
- Clocking (Word Clock Input Termination)
- 75 Ohms (Switchable)
- Maximum Output Level (Line/Monitor Outputs)
- +24 dBu (+4 dBu) +10 dBV (-10 dBV)
